Aging Test Chamber
Carbon Arc Lamp Aging Test Chamber
Product Description
1. The xenon lamp test chamber should use a sunlight-type carbon arc lamp as the radiation light source, control temperature, relative temperature, regular spraying, and be equipped with functions such as a rotatable sample rack. It is an equipment that simulates natural gas elements for artificial climate accelerated aging tests.
2. The Carbon Arc aging test chamber uses a xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves that exist in different environments. It can provide corresponding environmental simulation and accelerated testing for scientific research, product development and quality control.
Features
1. The xenon lamp test chamber should use a sunlight-type carbon arc lamp as the radiation light source, control temperature, relative temperature, regular spraying, and be equipped with functions such as a rotatable sample rack. It is an equipment that simulates natural gas elements for artificial climate accelerated aging tests.
2. The Carbon Arc aging test chamber uses a xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves that exist in different environments. It can provide corresponding environmental simulation and accelerated testing for scientific research, product development and quality control.
Technical parameters
|
Product Name |
HYTD-1000 |
|
Internal size(WxHxD)cm |
160X200X150 |
|
External size(WxHxD)cm |
98X98X98 |
|
Temp and humid range |
Workroom temperature: 38~85℃ |
|
Sample rack temperature: Blackboard temperature(BPT): 40~110℃; Blackboard standard temperature(BST): 40℃~120℃
|
|
|
Working humidity range: When exposed to light: 10-75%RH |
|
|
Temp fluctuations |
±2℃ |
|
Light source type |
Sunlight type carbon rod (Continuous lighting for 78 hours) |
|
Irradiance |
Light irradiance automatic control system |
|
Material |
Inside and outside stainless steel SUS304 |
|
Insulation Materials |
German Bayer fire-resistant high-strength PU polyurethane foam insulation material+ ultra-fine glass fiber |
|
Carbon rod quantity |
4 pairs, sunlight type carbon rod |
|
Sample rack |
The diameter ofthe sample holderis 960mm+3mm |
|
Sample |
76 standard sample racks (75X150mm standard samples) |
|
Arc voltage current |
Arc voltage, arc current direct display and automatic control |
