Composite Environmental Test Chamber

Conventional Salt Spray Tester/Environmental Salt Spray Test Chamber

Salt Spray Tester, also known as a Salt Spray Chamber or Fog Apparatus, is a crucial tool for assessing the anti-corrosion quality of materials surfaces after various protective treatments. Coatings, such as those from painting, coating, electroplating, anodizing, or greasing, undergo the salt spray test to determine their corrosion resistance.

product details

product description

Applications

Precision salt spray test chambers are widely used in aerospace, electronics, electrical appliances, communications, medical pharmaceuticals, colleges and universities, scientific research units and other industries to conduct environmental machine reliability tests on product appearance, temperature and humidity resistance, etc.

Features

‌-Precise control performance‌
-High stability and corrosion resistance‌
-Easy operation‌
-Safety performance‌
-Good sealing performance‌
-Automatic/manual water adding system‌
-Double over-temperature protection‌
-Temperature control‌
-Spray uniformity‌

Standards

GB/T2423.17-2008、GB/T2423.18-2021、IEC 60068-211-2021、ISO 9227、J1SH8502、GB/T10125、2021/1S092272006、DIN50021、ASTMG85GB-T5170.8-2017、GB-T5170.11-2017、1S09227、GB/T10587-2006、GJB-150.11A-2009、ISO 9227、ASTM B117、IEC 60068-2-11、ISO 16750-4、JISZ2371.

Technical Parameters

Model	HY-SST-60	HY-SST-90	HY-SST-120	HY-SST-160
Internal size(WxHxD)cm	60x45x40	90x60x50	120x80x50	160x100x60
Laboratory temperature	Salt water test method (NSS ACSS) 35℃±1C/Corrosion test method (CASS) 50℃±1℃
Pressure tank temperature	Salt water test method (NSS ACSS) 47°C±1°℃/Corrosion test method (CASS) 63°℃±1℃
Power	AC220±10V 10A	AC220±10V 15A	AC220±10V 30A
Test chamber volume(L)	108	270	480	960
Brine tank volume(L)	15	25	40	40
